Morel 12" Power Slim Dual 4 OHM Subwoofer
Morel 12" Power Slim Dual 4 OHM Subwoofer
FREE SHIPPING available for this item with any payment method!
Morel 12" Power Slim Dual 4 OHM Subwoofer: Unrivaled Bass, Compact Power
The Morel 12" Power Slim Dual 4 OHM Subwoofer takes bass performance to a whole new level with its compact yet powerful design. As part of the Ultimo PowerSlim series, this subwoofer redefines the possibilities of shallow subwoofer technology, offering exceptional performance in a slim profile.
Recognized with the prestigious EISA "Best In-Car Subwoofer" award for 2023-2024, the Ultimo PowerSlim is the ultimate solution for those who seek powerful bass in tight spaces without compromising on sound quality. Engineered with advanced technology and high-grade materials, it delivers dynamic, controlled, and precise bass reproduction that will elevate your audio experience.
Key Features:
Award-Winning Design: The Ultimo PowerSlim subwoofers were awarded the EISA "Best In-Car Subwoofer" for 2023-2024, underscoring their groundbreaking design and Morel's dedication to innovation.
EVC™ Motor Technology: The subwoofer features the advanced External Voice Coil (EVC™) motor with a massive 5.1-inch voice coil, providing unmatched power handling, superb linearity, and outstanding control for dynamic bass output.
Hexatech™ Aluminum Voice Coil Wire: The lightweight aluminum wire enhances the voice coil’s power handling capacity, ensuring high output without compromising on performance.
Uniflow Die-Cast Aluminum Chassis: The robust chassis design allows for exceptional excursion, maximizing output while maintaining a shallow mounting depth.
Progressive Field Symmetry (PFS) Suspension: This unique suspension system ensures optimal movement, enabling the subwoofer to produce deep and accurate bass, even with a shallow profile.
HexaCore Carbon Fiber and Aluminum Honeycomb Cone: The cone’s advanced materials deliver rigidity and control, contributing to exceptional bass dynamics and clarity.
Optimized Enclosure Compatibility: The Ultimo PowerSlim is designed to perform in enclosures nearly half the size of traditional subwoofers, offering versatility and ease of installation in compact spaces.
Specification:
- Configuration: 12"
- Impedance: 4+4 Ohms
- Power Handling (RMS): 700W RMS
- Power Handling (Max): 2,100W
- Sensitivity: 83 dB
- Frequency Response: 20 Hz - 500 Hz
- Resonance Frequency (Fs): 24 Hz
- Voice Coil Diameter: 129.5mm
- Voice Coil Height: 30mm
- Voice Coil Former: Aluminum
- Voice Coil Wire: Hexatech™ Aluminum
- DC Resistance (VC in parallel): 1.6 Ohms
- Voice Coil Inductance @ 1kHz (mH): 0.5 mH
- Magnet System: Double Magnet EVC
- Magnetic Gap Height: 8mm
- BL Product/BXL: 8.1
- Max. Linear Excursion (Xmax): ±11mm
- Cone Type: Flat Honeycomb
- Cone Material: 4 Layers of Carbon
- Unit Diameter: 305mm (12")
- Mounting Depth: 86mm
- Mounting Cutout: 268.6mm
- Net Weight: 5500 grams
- Grille: Included
- Recommended Sealed Enclosure: 22.7 Litres (0.8 cuft)
- Recommended Ported Enclosure: 39.64 Litres (1.4 cuft)
What's Included:
- 1x Morel 12" Power Slim Dual 4 OHM Subwoofer
- Protective Grille
- Mounting Solutions
- Installation Guide
Installation:
To install the Morel 12" Power Slim Dual 4 OHM Subwoofer, select a suitable enclosure size based on the recommended specifications. For optimal performance, the subwoofer can be installed in a sealed enclosure of 22.7 liters (0.8 cuft) or a ported enclosure of 39.64 liters (1.4 cuft). The shallow mounting depth allows for versatile placement in tight spaces, while the included grille offers additional protection.
