Morel 4-Channel Class-D Compact Amplifier - 4x 70W @ 4 OHMS/ 4x 100W @ 2 OHMS

FREE SHIPPING available for this item with any payment method!

Morel 4-Channel Class-D Compact Amplifier - 4x 70W @ 4 OHMS / 4x 100W @ 2 OHMS: Compact Power and Clarity for Your Car Audio System

The Morel MPD 4-Channel Class-D Amplifier is designed to deliver high-end, distortion-free sound in a space-saving package. Whether you’re upgrading your in-car audio system or seeking to maximize your available space, this amplifier offers powerful performance without sacrificing sound quality. With a sleek, compact design (48 x 148 x 195.5mm), the MPD4.70 fits easily into your vehicle, ensuring you can enjoy high-quality sound anywhere.

Offering 4x 70W at 4 ohms, 4x 100W at 2 ohms, and 2x 200W bridged at 4 ohms, the MPD4.70 is versatile enough to power speakers or subwoofers, delivering crystal-clear audio with impressive power and clarity. Whether you prefer deep bass or crisp highs, this amplifier lets you customize your sound with advanced crossovers and protection features that ensure long-lasting performance.

Key Features:

Compact Yet Powerful: Delivers 4x 70W at 4 ohms, 4x 100W at 2 ohms, and 2x 200W bridged at 4 ohms, providing versatile power for a variety of systems in a compact size.

Exceptional Sound Quality: With a frequency response of 20Hz to 30kHz and a signal-to-noise ratio over 93dB, this amplifier ensures full-range audio reproduction with sonic clarity.

Low Total Harmonic Distortion: The MPD4.70 maintains Total Harmonic Distortion (THD) below 0.2%, ensuring minimal distortion for a pure, clear audio experience.

Advanced Crossover Controls: Customize your audio output with variable high-pass and low-pass crossovers (50-300Hz, 12dB slope) to perfectly match your system's components.

Built-In Protection Circuit: Integrated protection ensures the amplifier operates reliably, safeguarding your investment and enhancing the longevity of your setup.

Space-Saving Design: The ultra-compact dimensions (48mm x 148mm x 195.5mm) allow for easy installation even in tight spaces, ideal for vehicles with limited room for components.

Specification:

• Power at 4 Ohms: 4x 70W
• Power at 2 Ohms: 4x 100W
• Power Bridged at 4 Ohms: 2x 200W
• Minimum Impedance: 2 Ohms
• Total Harmonic Distortion (THD+N): <0.2%
• Frequency Response (+/-1dB): 20Hz - 30kHz
• S/N Ratio (Rated Power, A-weighted): >93dB
• Channel Separation: >50dB
• Input Voltage Range: 0.35V - 3.5V
• Preamp Filters: HPF OFF-300Hz for Group A, LPF/HPF 50Hz - 300Hz for Group B
• Preamp Crossover Slope: 12dB/Octave
• Fuse Recommendation: 50A (Inline fuse must be used within 400mm of the battery)
• Dimensions: 48mm (H) x 148mm (W) x 195.5mm (L)

What's Included:

• 1x Morel 4-Channel Class-D Compact Amplifier
• Installation Accessories
• User Manual

Installation:

The Morel 4-Channel Class-D Compact Amplifier can be installed in most vehicles with limited space. Mount the amplifier securely in a well-ventilated area, and connect the necessary power, ground, and signal cables as outlined in the user manual. Use the recommended fuse to protect the system, and adjust the preamp filters to match your speaker or subwoofer setup for optimal sound quality.
