Morel Mono Class-D Compact Amplifier - 1x 350w @ 4 OHMS

FREE SHIPPING available for this item with any payment method!

Morel Mono Class-D Compact Amplifier - 1x 350w @ 4 OHMS

Powerful Bass in a Compact Package for Your Car Audio System

The Morel MPD Mono Class-D Amplifier delivers powerful, deep bass while maintaining a compact design, making it ideal for car audio enthusiasts who want high-end sound without sacrificing space. With its ultra-compact size (48mm x 148mm x 181.5mm), this amplifier fits easily in your vehicle, adding impactful bass that enhances your driving experience.

Offering 1x 350W at 4 ohms and 1x 550W at 2 ohms, the MPD1.500 is specifically designed for subwoofers, ensuring deep, resonant bass and precise sound reproduction. The amplifier features low Total Harmonic Distortion (THD) for clean, distortion-free sound, and advanced crossovers to fine-tune your bass output. Whether you’re upgrading your car's audio or adding more punch to your system, the MPD1.500 is a powerful and space-efficient solution.

Key Features:

Compact Yet Powerful: Delivers 1x 350W at 4 ohms and 1x 550W at 2 ohms, offering substantial power in a small footprint perfect for tight spaces.

Optimized for Bass: Designed specifically for subwoofers, it provides rich, deep bass with precision.

Exceptional Sound Quality: With a frequency response of 10Hz to 220Hz and THD less than 0.3%, the amplifier ensures clear, distortion-free bass.

Variable Crossovers: Customizable low-pass (40-220Hz) and sub-sonic (OFF-50Hz) crossovers allow you to tailor the bass to your exact preferences.

Built-In Protection Circuit: Safeguards the amplifier against overheating and other potential damage, ensuring long-lasting performance.

Space-Saving Design: The compact size (48mm x 148mm x 181.5mm) fits easily into vehicles with limited space.

Specification:

• Power at 4 Ohms: 1x 350W
• Power at 2 Ohms: 1x 550W
• Minimum Impedance: 2 Ohms
• Total Harmonic Distortion (THD+N): <0.3%
• Frequency Response (+/-1dB): 10Hz - 220Hz
• S/N Ratio (Rated Power, A-weighted): >98dB
• Channel Separation: N/A
• Input Voltage Range: 0.35V - 3.5V (Preamp Input), 0.7V - 7V (Speaker Input)
• Preamp Filters: LPF 40220Hz, Subsonic OFF50Hz
• Preamp Crossover Slope: 12dB/Octave
• Fuse Recommendation: 60A (inline fuse must be used within 400mm of the battery)
• Dimensions: 48mm (H) x 148mm (W) x 181.5mm (L)

What's Included:

• 1x Morel Mono Class-D Compact Amplifier
• Installation Accessories
• User Manual
