Zapco 240V AC to 9-16V DC Power Converter - 100A

Power your Zapco Amplifier or other DC-powered devices directly from a standard AC outlet with the Zapco Z-PS220I Power Converter. For over 40 years, Zapco has been the go-to choice for car audio enthusiasts, and now they offer a powerful tool for your setup, whether in a competition or for your home or office audio system.

This low noise, high-efficiency AC to DC power converter is built to Zapco’s standards and provides a steady and reliable DC current from a 110V or 220V AC outlet. With up to 100 amps of DC current adjustable between 9V to 16V, the Z-PS220I is perfect for driving Zapco amplifiers or powering other high-performance audio devices. Plus, multiple units can be “strapped” together, providing up to 400 amps of DC current for even the most demanding setups.

Whether you’re tuning your system, competing in an audio contest, or setting up a test bench, the Z-PS220I ensures your Zapco amplifier gets the power it needs without draining your car’s battery.

Key Features:

Adjustable Output Voltage
The Zapco Z-PS220I features an adjustable regulated output voltage between 9V~16V DC, ensuring compatibility with a wide range of devices and providing the flexibility you need.

Remote Volt Meter
Included with the converter is a remote panel-mount volt meter that lets you easily monitor the output voltage, ensuring your equipment operates within the desired range.

High Current Capacity
Delivering 100 amps of continuous DC current, the Z-PS220I powers your system reliably. If you need more power, multiple units can be strapped together, allowing you to scale up to 400 amps of current.

Temperature Controlled Cooling Fans
The Z-PS220I is equipped with temperature-controlled cooling fans to maintain optimal performance, preventing overheating during prolonged use.

Thermal and Overcurrent Protection
This power converter comes with thermal shut-off protection and over-current protection, safeguarding your equipment from potential damage during extreme conditions or overloads.

Pulse Charging for Battery Health
With its pulse charging technology, the Z-PS220I helps prevent battery sulfating (overcharging), maintaining the health of your battery for longer-lasting performance.

Specifications:

• Design: Switching Type
• Input Voltage: 220V AC ±10%
• Input Frequency: 50Hz~60Hz
• DC Output: Adjustable 9V~16V DC ±0.5V
• Output Current: 100 Amps DC Continuous (Maximum)
• Line Regulation: < ±5%
• Load Regulation: < ±5%
• Fuse: 10A/250V (Input Voltage: 220V)
• Output Ripple: 150 mV RMS
• Protection: Thermal Protection at 75°C, Overload Protection (UL more than 105 Amps)
• Cable: UL 14 AWG
• Dimensions (mm): 190(W) x 62(H) x 313(L)

Whether you need to save your battery during long tuning sessions, power multiple amplifiers during competitions, or create a test bench setup at home, the Zapco Z-PS220I Power Converter is the ultimate solution for all your power needs.

Order your Zapco 240V AC to 9-16V DC Power Converter today and elevate your audio experience with consistent, reliable power!
